high tension electro copper coated steel wire

NAME Frange dia
(mm)		 Inside dia (mm) Traverse (mm) Bore dia (mm) Overall length (mm) Reel weight (kg) Net weight (kg) Material
P-3 130 60 90 20 110 0.170 3～4 ABS resin
P-5 160 70 90 20 114 0.300 5～6 ABS resin
P-10 200 90 110 25 134 0.500 10 ABS resin
NS-5 120 54 130 15 150 0.195 5 ABS resin
NS-10 202 117 152 32 187 0.900 10 ABS resin
35LBS 200 90 150 28 166 0.430 15 ABS resin
PT-25 215
230		 110
130		 250 32 280 1.000 25 ABS resin
P-20K 270 148 90 52 103 0.700 20 PBS
ABS
50Kg Reel 340 200 219 80 255 4.500 40～50 ABS resin
Steel Reel A 340 180 250 65 270 22 70～80 Steel
Steel Reel B 555 270 340 50 380 33 200～270 Steel
Steel Reel C 600 280 295 53 340 43 200～270 Steel
Steel Reel D 500 296 300 100 330 66 150 Steel
Steel Reel E 555 270 150 50 185 24 100 Steel
500Kg Reel 600 360 552 90 588 14.5 500 Plywood
Hard Board 220 140 150 35 165 0.90 15 Hard Bord
Wire Band Reel 1,120 520 134 80 170 30 500 Plywood
